People working in mapping, surveying, or construction often know the limits of conventional data capture. Terrestrial Laser Scanners (TLS) deliver excellent precision, but they take time to set up, rely on ground control points, and often funnel teams into complex post-processing workflows that introduce delays and inaccuracies. On active job sites, that friction is more than an inconvenience. As David Epps of Envision Construction put it in a recent Geo Week News webinar, “Scanning is easy. Uncertainty is expensive.” His team evaluates every project at the outset and only deploys scanning when and where it meaningfully reduces risk or improves decision-making, a discipline that has become essential now that reality capture tools have proliferated across the industry.
That tension between precision and practicality is exactly what Exyn Technologies set out to solve with Nexys, a modular 3D mapping solution introduced in 2024. Handheld or mountable to a drone, ground robot, vehicle, or backpack, Nexys uses mobile SLAM technology and proprietary algorithms to capture survey-grade point clouds with real-time colorization and no dependence on GPS. As James Sui, Exyn’s Product Management Lead, explained in a Geo Week News webinar titled “Rethinking Precision: How RTK Elevates Lidar Scanning with Nexys,”
“We learned that autonomous robots by themselves are not super useful for our users — it’s the 3D data that comes out of them.”
That insight has driven nearly a decade of work refining LiDAR SLAM for survey teams worldwide, and it’s the reasoning behind Nexys’s design as a flexible, modular system rather than a single-purpose device. Since it can navigate autonomously through GPS-denied environments, it’s become a natural fit for underground projects and complex outdoor sites where traditional positioning systems fall short.
Choosing the Right Tool for the Job
Construction teams today aren’t short on reality-capture options; they can choose between TLS, SLAM, drones, GNSS units, and 360 cameras (the now-familiar “shark fin” hard-hat cameras popularized by platforms like OpenSpace and HoloBuilder), which are all in play. Many practitioners have traced this proliferation back to a simple frustration: field crews taking photos on their phones with no way to place those images in a digital context. That gap drove the partnerships and hardware that now span the entire project lifecycle, from pre-construction condition assessments to progress monitoring, embedded documentation, and post-construction warranty support.
The real challenge is no longer access to tools but the discipline in matching the right one to the task. TLS remains the choice for high-accuracy work like floor flatness studies and fabrication-level as-builts. SLAM scanners like Nexys shine in large interior walkthroughs and GPS-denied environments like underground utilities or complex outdoor terrain where speed matters more than millimeter precision. Drones cover open sites and aerial progress tracking, with LiDAR payloads brought in when terrain needs to be captured through tree canopies. Increasingly, teams blend approaches: SLAM for broad coverage and TLS dropped in only where precision is non-negotiable, a hybrid workflow that mirrors exactly the kind of flexible, multi-mount deployment Nexys was built to support.
Where Complexity Really Lives
Both webinars point to the same underlying truth: the hardest problems in reality capture aren’t about the sensors; they’re operational. Sui emphasized that outdoor workflows demand more than “just capturing the data”; it’s capturing it quickly and accurately with minimal setup time and without introducing unnecessary complexity. “That’s why Nexys pairs SLAM with RTK GNSS, letting outdoor teams tap into satellite-based correction networks instead of laying traditional ground control, cutting setup time while improving geospatial alignment and repeatability across projects.”
On the ground, that same drive to reduce friction shows up in deployment logistics. Many practitioners have developed pre-deployment checklists born from practical experience: Is the floor swept? Is it dry? Lasers don’t perform well around standing water. Can the scanner be positioned without blocking equipment operators? A TLS on a tripod in the middle of a busy site draws glares from forklift operators fast. Occasionally a drone wins simply because it can fly over everything, even if the resulting data is less precise, and drone docks are emerging as a way to take humans out of the on-site requirements entirely. These are exactly the kinds of operational complexity pain points a fast-deploying, modular system like Nexys is built to sidestep.
From Data to Decisions
Capturing the point cloud is only half the job; the bigger challenge is making that data usable. Point clouds look pixelated and intimidating to non-specialists, and asking field engineers to learn new software on top of their existing workload is a losing proposition. Platforms like FARO Sphere are closing that gap by presenting scan data in a familiar walkthrough interface while retaining the measurement capabilities of the underlying scan. Newer rendering approaches like Gaussian splats are gaining traction for the same reason: they produce visually clean walkthroughs that eliminate the pixelated look that turns off non-technical users, while still allowing real measurements to be pulled when a lidar backend is present.This matters because the payoff often comes from what scanning catches that nobody was looking for. The better the data, the more these conflicts surface before they become crises—which is precisely the value proposition behind Nexys’s combination of speed, autonomy, and accuracy.
Data at Scale, and the Internal Education Gap
As scan datasets grow, managing them becomes its own discipline. Practitioners have described a single exported LAS file of 350 gigabytes and 25 billion points, far beyond what most software can handle. The practical approach: decimate point clouds via grid-based sampling to reduce file size for sharing while preserving full density where precision matters, and organize data by structure, floor, or system rather than exporting one giant file. For archiving, lower-cost cloud storage options handle data that won’t be accessed frequently; for sharing with clients and field teams, web-based platforms allow navigation without specialized software.
Counterintuitively, the bigger education challenge today is internal, not external. Owners largely just want the building built correctly and rarely ask which tools are being used. The harder sell is to field engineers and superintendents who are skeptical of new workflows and already stretched thin. The strategy that works is making data available in interfaces people already understand, reducing workload rather than adding to it, and surfacing insights rather than raw data.
What’s Next?
Both the Exyn team and field practitioners see AI accelerating this shift. Epps has used tools like Claude to automate point cloud decimation and BIM comparison, and Duncan’s team cut a four-hour workflow to one hour the same way. Neither expects AI to eliminate jobs in this field—rather, it will shift them, freeing specialists to focus on higher-value analysis instead of manual data wrangling. On the horizon: automated data capture through drone docks and robotic systems, AI-powered progress tracking tied to 4D scheduling, automated point cloud classification, and robotic layout systems that can mark up a slab in a fraction of the time a human crew would need. As Sui noted in the Geo Week News webinar, customers are already extending Nexys and SLAM data well past its original as-built, progress-monitoring, and QA use cases into stockpile volumetrics, cut/fill analysis, and BIM generation as inputs.
The common thread across every use case, every checklist, and every anecdote: reducing operational complexity so field teams can spend less time wrangling data and more time acting on it.
See Nexys in Action
Learn how Nexys helps construction and surveying teams simplify reality capture workflows while delivering fast, accurate, survey-grade data. Request a demo to see how it can fit into your operations.
